Basic Info.
Product Description
Automatic Facial Tissue Widening Into Box Sealing Machine
Product profile
Applicaton range:
It is suitable for widened automatic boxing of facial
tissues, square tissues, pocket tissues, cotton
tissues etc.
Five innovations of the machine:
1,High output. The stable speed can reach 80 boxes/minute.
2,Complete functions. The machine is suitable for various applications such as
semi-cover/full-cover, or high paper and low box/low paper and high box.
3,Rapid production. It only takes 10-20 minutes to change the specifications.
4,Convenient operation. It is easy to control the servo paper feeding
and PLC control system.
5,Low cost. The imported glue machine with a nozzle of 0.3-0.36mm
is adopted and the glue-spread is little.
Main technical parameters:
| Item/model | STZ-140 |
| Packaging specifications | L100-240mm×W100-140mm×H30-90mm |
| Production capacity | 30-80 (boxes/minute) |
| total power | 6.7kw |
| power type | Three-phase four-wire 380V 50Hz |
| Air supply | 0.5Mpa-0.8Mpa |
| Air consumption | 120-160L/H |
| Main machine part | L3619×W1406×H1860mm |
| Size of conveying mechanism | L1758mm X W383mm×H1400mm |
| Machine weight | 2500KG |
